TR2215-LBC24
TR
Product Overview
A Current Transducer, also known as a Power Transducer, is a precision device that measures electrical current and converts it into a standardized output signal for monitoring, control, and protection purposes. It provides accurate, stable, and real-time current data, helping ensure safe and efficient operation of electrical systems. With high accuracy, fast response, and strong electrical isolation, it is suitable for both AC and DC applications. Widely used in industrial automation, power distribution, renewable energy systems, motor monitoring, and energy management, this device integrates easily with PLCs, meters, and data acquisition systems to support reliable electrical measurement and control.
Products Features
High accuracy and stable current measurement
Strong electrical isolation for enhanced safety
Fast response to AC and DC current changes
Easy integration with control and monitoring systems
Applications
Industrial automation and process control
Power distribution panels and monitoring systems
Renewable energy systems, including solar and wind
Motor protection, HVAC systems, and energy management
Download Size Sheet
Mechanical Dimension(mm)
Technical Data
| Electrical Parameters | Primary Measuring Range | 0-1500A AC | Secondary Rated Output | 0-10V, 4-20mA,RS485 |
| Accuracy | 0.30% | Linearity | 0.30% | |
| Load Capacity | Current type: ≤500Ω, Voltage type: ≥10KΩ | Offset Voltage | 10mV (for output voltage ignal) | |
| Response Time | <200ms | Temperature Drift | ≤500PPM/℃ | |
| Power Supply Voltage | DC 12V/DC 24V/AC 220V | Response Time | <200ms | |
| Power Consumption | ≤1W | Power Frequency Withstand Voltage | 1.5kV AC/1min | |
| Operating Environment | Ambient Operating Temperature | -10℃-+70℃ | Ambient Storage Temperature | -25℃-+85℃ |
