Products Features
* High precision measurement of three-phase AC current.
* With high ability and precision power paremeter.
* Multiple display digits.
* Flexible installation.
* Wide measurement range, compatible with different current ratings.
Product Application
Multifunction with best competitive, can direct instead of general power transmittedmeasure meter, power energy measure meter and relative auxiliary unit, have widelyapplication, like energy manage system,power monitor system, industry and miningenterprise, publice place, intelligent building and switch board those power net system.
| Outline Dimension (L×H) | Board assemble dimersion (A×B) | Open dimension (S×Y) | Total Length (N) | Deepth (M) |
| 48×48 | 44×44 | 45×45 | 90 | 84 |
| 48×96 | 90×44 | 92×45 | 93 | 78 |
| 72×72 | 67×67 | 68×68 | 93 | 78 |
| 80×80 | 75×75 | 76×76 | 93 | 78 |
| 96×96 | 91×91 | 92×92 | 93 | 78 |
| 120×120 | 110×110 | 111×111 | 93 | 78 |
Product Parameters
| Parameter | |||
| Connection | Three phase four wires / three phase three wires | ||
| Signal Input | Current | Measurement Range | AC 1A, 5A |
Overload | Continuous: 1.2 multiple; Instantaneous: 10 multiple/5s | ||
Power Consumption | ≤2VA | ||
Frequency | 45 ~ 65Hz | ||
Power Source | AC 220V, AC/DC 85 ~ 265V | ||
Display Digits | 4 digits; Display Range: 0.000 - 9999 | ||
Accuracy Class | 0.5, 0.2 class | ||
Insulation Strength | 2kV AC/1min | ||
Display | Special display, LCD display | ||
Environment | Working temperature: -10 ~ +55℃; Save temperature: -20 ~ +75℃; Relative Humidity: <80%RH | ||
