Digital Panel Meter
A Digital Panel Meter (DPM) is a full‑fledged electronic measuring instrument that converts incoming electrical signals into readable digital outputs on LED or LCD screens.
It measures voltage, current, power, energy and other parameters, available in single‑function and multi‑function versions. Current transformers are required for AC measurements.
It requires auxiliary power supply, and supports RS485 communication, alarm and analog transmission. Common standard cut‑out sizes include 48×96 mm and 72×72 mm.
It features high‑precision intuitive digital display, flexible panel‑mount installation and wide signal compatibility with optional alarm and communication functions.
It is widely applied in industrial distribution cabinets, power supply equipment and automatic machinery for real‑time electrical parameter monitoring.
Features
High‑precision
Eliminates parallax error of analog meters and delivers stable, clear readings.
Flexible installation
Supports standard panel cut‑out mounting to save space inside enclosures.
Broad signal compatibility
Accepts AC/DC voltage, current, temperature and other diversified input signals.
Expandable functions
Some versions are equipped with alarm output and communication interfaces for remote monitoring.
Applications
It is widely adopted in industrial distribution cabinets, power‑charging equipment and automated industrial machinery for real‑time monitoring of electrical parameters to support safe operation, debugging and equipment status management.
Industrial distribution cabinets
Used in power distribution panels and control cabinets to continuously monitor bus voltage, loop current and other power parameters. It helps operators quickly identify abnormal power conditions and maintain stable and safe power‑supply operation.
Power & charging equipment
Installed on switching power supplies, inverters and industrial chargers to show real‑time output voltage and current. It provides intuitive operating data for equipment debugging, daily inspection and fault diagnosis.
Automated industrial machinery
1. Integrated into machine tools, production lines and other industrial devices. It keeps real‑time tracking of critical working parameters, supporting on‑site status observation and equipment condition management.
Product Advantages
Innovative R&D Capabilities
With strong independent R&D strength, we continuously optimize hardware circuits and software algorithms to deliver reliable, high‑performance digital panel meters.
Customized design support
Flexible customization for input signals, display modes and functional interfaces to meet diverse project requirements.
Optimized circuit architecture
Adopt mature ADC sampling circuits to ensure stable measurement performance and low signal interference.
Iterative product upgrading
Keep improving product functions based on market feedback, and expand optional alarm and communication modules.
technical document
- Name
- Update
- Size
- Downloads
- Thumbnail
- Download
- Copy Link
- digital panel meter.pdf
- 2026-09-10
- 1.63MB
- 5
-
- Download
- Copy Link
Company Advantages（Why choose us）
Rich industry experience
28 Years of experience in the electrical instrument field, with deep understanding of global market demands and various application scenarios.
Strict quality control
Complete production and testing procedures, each product undergoes multiple inspections to guarantee stable and reliable performance.
Competitive supply capacity
Testimonials
The high‑precision measurement and stable performance of these digital panel meters perfectly match our industrial cabinet projects. The product quality is reliable and the installation is straightforward.
Daniel Brown
We are satisfied with both the product and service. The meters deliver accurate readings, and the fast lead‑time supports our bulk‑order production schedule very well.
Sophia Miller
These digital panel meters deliver precise readings and work stably in our building energy‑management projects. Installation is simple, and the product quality meets our high‑end requirements.
Olivia Carter
We have used these meters for multiple municipal and industrial projects. The reliable performance and on‑time delivery greatly support our business development.
Isabella Reed
