Product Features
Mensuratio* currens parva stabilis est.
* Praeclara accuratio,' good linerity.
Lata metiendi* amplitudine, ac valido onero capacitatis.
* Perforata compage, nullo inserto detrimento.
Product Applicationem
Signum * ratio.
* Linea deprehensio.
* Leakage Cras System.
Dif- vena* tae.
Morbi condimentum
Specification |
10mA/5V |
50mA/5V |
200mA/5V |
Unitas |
ego PN |
Primary Rated Input Current (DC) |
10 |
50 |
200 |
ma |
ego P |
Primaria Current mensurae dolor |
0-15 |
0-75 |
0-300 |
ma |
V SN |
Secundarium rated output voltage (DC) |
5 |
V |
V C |
Virtus Supple Voltage |
±12-15(±5%) |
V |
I C |
Current Consummatio |
30 |
ma |
V d |
Insulatio Voltage |
Inter primos et secundos circuitus: 2.5kV/50Hz/1min |
|
ε L |
Linearity |
1 |
%FS |
X |
Precision |
TA=25℃:≤±0.5 |
% |
V0 |
Offset intentione |
TA=25℃:≤±50 |
mV* |
V OT |
Offset intentione Temperature Drift |
Ip =0 TA =-40-+80℃:≤±1.5 |
mV/℃ |
T r * |
Responsio Tempus |
≤120 |
mS* |
T A |
Operatio Temperature |
-40-+80 |
℃ |
T S |
Repono Temperature |
-45-+85 |
℃ |
R L |
Onus Resistentia |
TA=25℃:≥10 |
kΩ |
Dimensiones
Electrical Schematic
Nota |
|
ego PN : |
Primaria current initus directionis |
+ : |
Positivum 12V/15V potentia copia |
- : |
Negative 12V/15V potentia copia |
M : |
Signum secundarium output |
| G : |
Potentia terram |
| OFS: |
Nulla temperatio |
Cautiones instruitur
Sensorem hodiernum recte filum esse debet, alioquin sensorem internum laedat.
